Electric Motors

1 - 20 of 1692

Compare Product

Fire Pump Motor, 125 & 100 HP, 3 Ph, 60 & 50 Hz, 460 & 380-400 V, 3600 & 3000 RPM, 404TS Frame, DP

Part #:404TSTDCD4017

Catalog #:U530A

List Price: $19,989.00

frame_inspect View Details location_on Where to Buy

Key Features

Designed for use on pumps for fire pump duty
UL file EX5190, CSA file LR2025 and CE mark
50°C ambient
Red paint on 25 HP through 200 HP
NEMA Design B, Code G or less
Will accept C-Face kits.
Single voltage motors have 12 leads and are suitable for wye-delta, across the line, or part winding start
Dual voltage motors have 12 leads, suitable for wye-delta or across the line start on either voltage, or part winding start on low voltage
Rated 60/50 hertz, 190/380 or 380 volt at next lower horsepower

Check Inventory

Compare Product

Fire Pump Motor, 100 & 75 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1800 & 1500 RPM, 404TS Frame, DP

Part #:404TSTDCD4334

Catalog #:U528B

List Price: $14,137.00

frame_inspect View Details location_on Where to Buy

Key Features

IP22, NEMA® EPACT Efficiency, Fire Pump motors are not recommended for use with variable frequency drives.
NEMA® design B, code G or less
Dual voltage motors have 12 leads, suitable for wye-delta or across the line start on either voltage, or part winding start on low voltage
Single voltage motors have 12 leads and are suitable for wye-delta, across the line, or part winding start
Class F Insulation, 50C Max Ambient, 1.15 service factor (except as noted)
Red paint on 25 HP through 250 HP
Ball bearings
Will accept C-Face kits (except as noted), see accessories section for kits
UL file EX5190, CSA file LR2025 and CE mark
Will become build-up item when current stock is gone

Check Inventory

Compare Product

Fire Pump Motor, 500 & 400 HP, 3 Ph, 60 & 50 Hz, 460 & 380 V, 1800 & 1500 RPM, 449TS Frame, DP

Part #:449TSTDN7027

Catalog #:H816

List Price: $58,328.00

frame_inspect View Details location_on Where to Buy

Key Features

Designed for use on pumps for fire pump duty
UL file EX5190, CSA file LR2025 and CE mark
50°C ambient
Red paint on 25 HP through 200 HP
NEMA Design B, Code G or less
Rated 60/50 hertz, 190/380 or 380 volt at next lower horsepower
Single voltage motors have 12 leads and are suitable for wye-delta, across the line, or part winding start
Dual voltage motors have 12 leads, suitable for wye-delta or across the line start on either voltage, or part winding start on low voltage

Check Inventory

Compare Product

Fire Pump Motor, 500 & 400 HP, 3 Ph, 60 & 50 Hz, 460 & 380 V, 3600 & 3000 RPM, 449TS Frame, DP

Part #:449TSTDN14005

Catalog #:H819A

List Price: $70,666.00

frame_inspect View Details location_on Where to Buy

Key Features

Designed for use on pumps for fire pump duty
UL file EX5190, CSA file LR2025 and CE mark
50°C ambient
Red paint on 25 HP through 200 HP
NEMA Design B, Code G or less
Rated 60/50 hertz, 190/380 or 380 volt at next lower horsepower
Single voltage motors have 12 leads and are suitable for wye-delta, across the line, or part winding start
Dual voltage motors have 12 leads, suitable for wye-delta or across the line start on either voltage, or part winding start on low voltage

Check Inventory

Compare Product

Fire Pump Motor, 450 & 350 HP, 3 Ph, 60 & 50 Hz, 460 & 380 V, 1800 & 1500 RPM, 449TS Frame, DP

Part #:449TSTDN14033

Catalog #:H815A

List Price: $57,267.00

frame_inspect View Details location_on Where to Buy

Key Features

Designed for use on pumps for fire pump duty
UL file EX5190, CSA file LR2025 and CE mark
50°C ambient
Red paint on 25 HP through 200 HP
NEMA Design B, Code G or less
Rated 60/50 hertz, 190/380 or 380 volt at next lower horsepower
Single voltage motors have 12 leads and are suitable for wye-delta, across the line, or part winding start
Dual voltage motors have 12 leads, suitable for wye-delta or across the line start on either voltage, or part winding start on low voltage

Check Inventory

Compare Product

Fire Pump Motor, 300 & 250 HP, 3 Ph, 60 & 50 Hz, 460 & 380 V, 1800 & 1500 RPM, 449T Frame, TEFC

Part #:449TTFS14057

Catalog #:Y1645

List Price: $51,333.00

frame_inspect View Details location_on Where to Buy

Key Features

Red paint exterior
NEMA Design B, Code G or less
Dual voltage motors have 12 leads, suitable for wye-delta or across the line start on either voltage, or part winding start on low voltage
Single voltage motors have 12 leads and are suitable for wye-delta, across the line, or part winding start
Will accept C- Face kits.
230/460 and 460 Volt models rated for 50 HZ at next lower HP
For special designs, contact district sales office near you

Check Inventory

Compare Product

Hydraulic Motor, 10 & 7.50 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1800 & 1500 RPM, 215TZ Frame, TEFC

Part #:141347.00

Catalog #:141347.00

frame_inspect View Details location_on Where to Buy

Key Features

Rolled steel and cast iron construction
Rigid base construction
230/460 Volt
IRIS™ Inverter insulation system
575 Volt ratings available - contact your local sales office
Higher HP SAE Pump motors available - contact your local sales office

Check Inventory

Compare Product

Washdown Pump Motor, 5 & 3 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 3600 & 3000 RPM, 184JM Frame, TEFC

Part #:132443.00

Catalog #:132443.00

List Price: $3,413.00

frame_inspect View Details location_on Where to Buy

Key Features

USDA-approved epoxy painted motors
NEMA motors
Rigid base and C face mount types
UL recognized and CSA certified
Double lip contact seals and v-ring seals used for shaft seals

Check Inventory

Compare Product

Close-Coupled Pump Motor, 5 HP, 1 Ph, 60 Hz, 208-230 V, 3600 RPM, 184JM Frame, DP

Part #:132634.00

Catalog #:132634.00

frame_inspect View Details location_on Where to Buy

Key Features

No features available

Check Inventory

Compare Product

Close-Coupled Pump Motor, 5 & 3 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1800 & 1500 RPM, 184JP Frame, DP

Part #:184TTDBD6037

Catalog #:GT2413A

List Price: $1,844.00

frame_inspect View Details location_on Where to Buy

Key Features

Meets or exceeds NEMA Premium® efficiency. Model is in compliance with EISA2007
Inverter Duty 20:1 Variable Torque and 2:1 Constant Torque
Nameplated 60/50 hertz, 190/380 volts at next lower HP
Steel frame with Class F Insulation
Standard F1, reversible to F2 assembly. Dual frame mounting holes.

Check Inventory

Compare Product

Vertical Pump Motor, 5 HP, 3 Ph, 60 Hz, 230/460 V, 1800 RPM, 184HPV Frame, DP

Part #:184TTDR16009

Catalog #:M804B

List Price: $3,570.00

frame_inspect View Details location_on Where to Buy

Key Features

Meets or exceeds NEMA Premium® efficiencies
Normal and Medium thrust
Ball bearings and angular contact bearings for medium thrust applications
Class F insulation
Suitable for 230 volt part winding start through 100 HP (dual voltage motors)
Heavy duty lifting lugs
Drip cover/canopy cap included

Check Inventory

Compare Product

Close-Coupled Pump Motor, 5 & 3 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 3600 & 3000 RPM, 184JM Frame, TEFC

Part #:184TTFBD6006

Catalog #:GT3112A

List Price: $2,491.00

frame_inspect View Details location_on Where to Buy

Key Features

Meets or exceeds NEMA Premium® efficiency. Model is in compliance with EISA2007
Hazardous Duty Division 2, Zone 2, Class I, Groups A,B,C,D, Temperature code T2B
1.15 service factor on sinewave, 1.0 service factor on IGBT power
Inverter Duty 20:1 Variable Torque and 10:1 Constant Torque
Class F Insulation
Standard F1, reversible to F2 assembly. Dual frame mounting holes.
NEMA JM pump shaft dimensions
JM frame has rigid base, drip cover not included
Dual frame mounting holes
UL recognized, CSA certified and CE mark
